An interface of a physical server. More...

#include <IServer.hpp>

Public Member Functions
	IServer ()
	Default Constructor. More...

virtual void	open ()
	Open the server. More...

virtual void	close ()
	Close the server. More...

Protected Member Functions
virtual auto	MY_IP () const -> std::string
	(optional) Server's IP More...

virtual auto	PORT () const -> int=NULL
	Port number of the server. More...

virtual void	addClient (Socket *)=0
	Handling connection of a physical client. More...

Protected Attributes
Acceptor *	acceptor
	An acceptor for clients. More...

Detailed Description

An interface of a physical server.

IServer provides methods for opening a server.

IServer is one of the basic 3 + 1 components that can make any type of network system in Samchon Framework with IProtocol and IClient. Looking around classes in Samchon Framework, you can see all servers are implemented from the IServer.

When a client connects to the server, the abstract method IServer::addClient() is called with a new thread. If you want to accept only a client at a time, use OneToOneServer instead.

Example source

A simple chat server running on console

example/console_chat_server/ChatServer.hpp: 1 #pragma once
2 #include <samchon/protocol/IServer.hpp>
3 #include <samchon/protocol/IProtocol.hpp>
4
5 #include <set>
6 #include <samchon/library/RWMutex.hpp>
7
8 namespace samchon
9 {
10 namespace example
11 {
21 namespace console_chat_server
22 {
23 class ChatClient;
24
30 class ChatServer
31 : public protocol::IServer,
32 public protocol::IProtocol
33 {
34 private:
35 typedef protocol::IServer super;
36
40 std::set<ChatClient*> clientSet;
41
45 library::RWMutex rwMutex;
46
47 public:
51 ChatServer();
52 virtual ~ChatServer() = default;
53
57 void eraseClient(ChatClient *client);
58
59 protected:
63 virtual auto PORT() const -> int override
64 {
65 return 37749;
66 };
67
71 virtual void addClient(protocol::Socket *socket) override;
72
73 public:
80 virtual void replyData(std::shared_ptr<protocol::Invoke>) override;
81
88 virtual void sendData(std::shared_ptr<protocol::Invoke>) override;
89 };
90 };
91 };
92 };
samchon::protocol::IServer::PORT
virtual auto PORT() const -> int=NULL
Port number of the server.

samchon::protocol::IServer::addClient
virtual void addClient(Socket *)=0
Handling connection of a physical client.

samchon
Top level namespace of products built from samchon.
Definition: ByteArray.hpp:7

example/console_chat_server/ChatServer.cpp: 1 #include <samchon/examples/console_chat_server/ChatServer.hpp>
2 #include <samchon/examples/console_chat_server/ChatClient.hpp>
3
4 #include <thread>
5 #include <samchon/protocol/Invoke.hpp>
6
7 using namespace std;
8 using namespace samchon::library;
9 using namespace samchon::protocol;
10 using namespace samchon::example::console_chat_server;
11
12 ChatServer::ChatServer()
13 : super()
14 {
15 }
16 void ChatServer::addClient(Socket *socket)
17 {
18 ChatClient *client = new ChatClient(this, socket);
19
20 UniqueWriteLock uk(rwMutex);
21 clientSet.insert(client);
22
23 thread(&ChatClient::listen, client).detach();
24 }
25 void ChatServer::eraseClient(ChatClient *client)
26 {
27 UniqueWriteLock uk(rwMutex);
28 clientSet.erase(client);
29 }
30
31 void ChatServer::replyData(shared_ptr<Invoke> invoke)
32 {
33 sendData(invoke);
34 }
35 void ChatServer::sendData(shared_ptr<Invoke> invoke)
36 {
37 UniqueReadLock uk(rwMutex);
38
39 for(auto it = clientSet.begin(); it != clientSet.end(); it++)
40 (*it)->sendData(invoke);
41 }
std
Definition: RWMutex.hpp:4

samchon::library
Package of libraries.
Definition: library.hpp:84

samchon::library::UniqueReadLock
Unique lock for reading.
Definition: UniqueReadLock.hpp:39

samchon::protocol
Package of network protocol and libraries.
Definition: protocol.hpp:185

samchon::example::console_chat_server::ChatClient
A chat client.
Definition: ChatClient.hpp:21

samchon::library::UniqueWriteLock
Unique lock for writing.
Definition: UniqueWriteLock.hpp:41

samchon::example::console_chat_server
A chat server.
Definition: ChatClient.hpp:8

example/console_chat_server/ChatClient.hpp: 1 #pragma once
2 #include <samchon/protocol/IClient.hpp>
3
4 namespace samchon
5 {
6 namespace example
7 {
8 namespace console_chat_server
9 {
10 class ChatServer;
11
21 class ChatClient
22 : public protocol::IClient
23 {
24 private:
25 typedef protocol::IClient super;
26
30 ChatServer *server;
31
32 public:
39 ChatClient(ChatServer*, protocol::Socket*);
40
45 virtual ~ChatClient();
46
51 virtual void replyData(std::shared_ptr<protocol::Invoke>) override;
52 };
53 };
54 };
55 };
samchon
Top level namespace of products built from samchon.
Definition: ByteArray.hpp:7

example/console_chat_server/ChatClient.cpp: 1 #include <samchon/examples/console_chat_server/ChatClient.hpp>
2 #include <samchon/examples/console_chat_server/ChatServer.hpp>
3
4 #include <samchon/protocol/Invoke.hpp>
5
6 using namespace std;
7 using namespace samchon::library;
8 using namespace samchon::protocol;
9 using namespace samchon::example::console_chat_server;
10
11 ChatClient::ChatClient(ChatServer *server, Socket *socket)
12 : super()
13 {
14 this->server = server;
15 this->socket = socket;
16 }
17 ChatClient::~ChatClient()
18 {
19 server->eraseClient(this);
20 }
21
22 void ChatClient::replyData(shared_ptr<Invoke> invoke)
23 {
24 server->replyData(invoke);
25 }
std
Definition: RWMutex.hpp:4

samchon::library
Package of libraries.
Definition: library.hpp:84

samchon::example::console_chat_server::ChatServer
A chat server.
Definition: ChatServer.hpp:30

samchon::protocol
Package of network protocol and libraries.
Definition: protocol.hpp:185

samchon::example::console_chat_server
A chat server.
Definition: ChatClient.hpp:8

example/console_chat_server/main.cpp: 1 #include <iostream>
2 #include <samchon/examples/console_chat_server/ChatServer.hpp>
3
4 #ifdef _WIN64
5 # ifdef _DEBUG
6 # pragma comment(lib, "x64/Debug/SamchonFramework.lib")
7 # else
8 # pragma comment(lib, "x64/Release/SamchonFramework.lib")
9 # endif
10 #else
11 # ifdef _DEBUG
12 # pragma comment(lib, "Debug/SamchonFramework.lib")
13 # else
14 # pragma comment(lib, "Release/SamchonFramework.lib")
15 # endif
16 #endif
17
18 using namespace samchon::example::console_chat_server;
19
20 void main()
21 {
22 ChatServer chatServer;
23 chatServer.open();
24
25 system("pause");
26 }
samchon::example::console_chat_server::ChatServer
A chat server.
Definition: ChatServer.hpp:30

samchon::example::console_chat_server
A chat server.
Definition: ChatClient.hpp:8
